MACHINE DESCRIPTION
MACHINE STRUCTURE
1. Control panel
2. Handlebar
3. Battery charger data inspection window (*)
4. Battery charger cable (*)
5. Battery charger cable holder (*)
6. Rear parking wheel
7. Squeegee lifting/lowering lever
8. Battery connector (red).
This connector also works as EMERGENCY push-button,
to stop immediately all functions.
9. Front wheels on xed axle
10. Squeegee vacuum hose
11. Recovery water drain hose
12. Solution drain and level check hose
13. Brush deck
14. Brush/pad-holder
15. Solution tank
16. Recovery tank
17. Recovery tank cover
18. Recovery tank cover (half-open)
19. Recovery tank cover (completely opened)
20. Can holder
21. Squeegee
22. Squeegee mounting handwheels
23. Squeegee balance adjusting handwheel
24. Machine straight forward movement adjusting handwheel
25. Machine forward speed adjusting handwheel
26. Tank cover gasket
27. Machine in parking position
28. Battery connection diagram
29. Serial number plate/technical data/conformity certication
30. Vacuum grid with automatic shut-off oat
31. Solution ller neck
32. Foam lter
33. Vacuum system motor
34. Solution lter
35. Solenoid valve
36. Solution ow control lever
37. Solution ow control lever ECO position (water “economy”
usage, for a washing autonomy set for ~ 90 minutes)
38. Batteries
39. Battery caps
40. Water removable ller hose (optional)
(*) Only with battery charger (optional) installed
8/12 Revised 4/14
