TECHNICAL DATA
Model SC450
Solution tank capacity 40 litres
Recovery tank capacity 45 litres
Machine length 1,180 mm
Machine width without squeegee 559 mm
Machine height 1,060 mm
Cleaning width 530 mm
Squeegee width 760 mm
Brush diameter 530 mm
Front wheel diameter 254 mm
Wheel specic pressure on the oor 4.9 N/mm
2
Brush/pad pressure (with full tank and lowered squeegee) 34 kg
Min/max solution ow 0.4 ÷ 1.6 L/min
ECO solution ow 0.4 L/min
Sound pressure level at workstation (ISO 11201, ISO 4871, EN 60335-2-72) (LpA) 68 dB(A) ± 3 dB(A)
Machine sound power level (ISO 3744, ISO 4871, EN 60335-2-72) (LwA) 85 dB(A)
Vibration level at the operator’s arms (ISO 5349-1, EN 60335-2-72) < 2.5 m/s
2
Maximum gradient when working 2 %
Protection class (IP) X4
Protection class (electric) III
Vacuum system motor power 330 W
Vacuum system circuit capacity 1,100 mm H
2
O
Brush motor power 480 W
Brush speed 154 rpm
Total absorbed power 0.8 kW
Battery compartment size (width x length x height) 350 x 350 x 300 mm
Battery voltage 24 V
Standard batteries (2) Dry: 12 V 70 Ah C5
Battery charger (optional) 100-240 VAC
Standard battery autonomy 2 hour
Weight without batteries and with empty tanks 70 kg
Gross vehicle weight (GVW) 190 kg
Shipping weight 97 kg
Machine material composition and recyclability
Type Recyclable
percentage
SC450
Aluminium 100 % 8 %
Electric motors - various 29 % 18 %
Ferrous materials 100 % 19 %
Wiring harness 80 % 1 %
Liquids 100 % 0 %
Plastic - non-recyclable material 0 % 1 %
Plastic - recyclable material 100 % 9 %
Polyethylene 92 % 42 %
Rubber 20 % 2 %
