Nilfisk-Advance SC450 User Manual

INSTRUCTION FOR USE ENGLISH
9099589000 - SC450 23
8/12
FUSE CHECK/REPLACEMENT
1. Disconnect the battery connector (8).
2. Move aside the recovery water drain hose (11).
3. Remove the battery charger cable, if equipped, from the cable holder (5).
4. Remove the screws (A, Fig. 10) and carefully move aside the panel (B) by disengaging the grommet (C) from its housing on
the panel (B).
5. Check/replace the following fuses:
• (D) Brush deck motor fuse F1 (40 A)
• (E) Vacuum system fuse F2 (30 A)
• (F) Electronic board fuse F3 (5 A)
6. Perform steps 1 to 4 in the reverse order.
EFD
A
A
B
A
C
Figure 10
P100670
