USER MANUAL ENGLISH
33019216 - SR 1601 D3 / LPG3 / P3 13
Performance data SR 1601 D3 SR 1601 LPG3 SR 1601 P3
Total power
16.3 kW
2750 rpm
19 kW
2650 rpm
20 kW
2650 rpm
Maximum forward speed (for transport only) 7.5 mph (12 km/h)
Maximum gradient when working 17% (9.6°)
Minimum turning radius 60.2 in (1,530 mm)
Sound pressure level at workstation (ISO 11201, ISO 4871, EN 60335-2-72) (LpA) 88 ±3 dB(A) 89 ±3 dB(A)
Machine sound pressure level (ISO 3744, ISO 4871, EN 60335-2-72) (LwA) 108 dB(A) 109 dB(A)
Vibration level at the operator’s arms (ISO 5349-1, EN 60335-2-72) <2.5 m/s
2
Vibration level at the operator’s body (ISO 2631-1, EN 60335-2-72) <0.5 m/s
2
Hopper capacity
Theoretic: 11.25 cu·ft (315 litres)
Real: 8.00 cu·ft (226 litres)
Hopper maximum lift capacity 800 lb (363 kg)
Dust guard system (equipped on SR 1601 MAXI) 11.9 USgal (45 litres)
WIRING DIAGRAM
Key
ALT Alternator
BAT Battery
BE1 Pivoting light (optional)
BZ1 Reverse gear buzzer (optional)
ES1 Vacuum system relay
ES2 Filter shaker relay
ES3 LPG safety relay (LPG3 version only)
EV1 Fuel solenoid valve (D3 and P3 versions only)
EV2 LPG solenoid valve (LPG3 version only)
EV3 LPG safety solenoid valve (LPG3 version only)
F1 Vacuum system fuse (30 A)
F2 Filter shaker fuse (16 A)
F3 Water pump fuse (10 A) (if equipped)
F4 Ignition key fuse (30 A)
F5 Engine accessory fuse (16 A)
F6 Working light fuse (10 A) (optional)
F8 Cab blower fuse (optional)
F9 Glow plug fuse (50 A) (D3 version only)
F10 Alternator fuse box and fuse (50 A)
F11 Hood inner light fuse (1 A) (optional)
HN Horn
IGN Ignition unit (LPG3 and P3 versions only)
K1 Ignition switch
L1 Front working light (optional)
L2 Front working light (optional)
L3 Driver’s side working light (optional)
L4 Rear working light (optional)
L5 Engine hood inner light (optional)
M1 Vacuum system motor
M2 Filter shaker motor
M3 Water pump motor (if equipped)
M4 Cab blower (optional)
M7 Windscreen wiper motor (optional)
MST Starter
P1 Fuel pump (P3 version only)
PLG Glow plug (D3 version only)
R1 Glow plug warning light resistance (D3 version only)
SE1 Oil pressure sensor
SE2 Water temperature sensor
SE3 Clogged hopper lter sensor (optional)
SE5 Fuel tank oat (D3 and P3 versions only)
SE6 Hopper temperature sensor (optional)
SE7 Engine speed sensor (LPG3 and P3 versions only)
SE8 Low fuel sensor (LPG3 version only)
SPK Glow plug coils (LPG3 and P3 versions only)
STR Gage
SW1 Vacuum system/lter shaker switch
SW2 Horn switch
SW3 Driver’s seat microswitch
SW4 Reverse gear proximity (optional)
SW5 Cab blower switch (optional)
SW6 Water pump switch (if equipped)
SW7 Working light switch (optional)
SW13 Driver’s side working light switch (optional)
SW14 Rear working light switch (optional)
SW15 Hood inner light switch (optional)
SW16 Windscreen wiper switch (optional)
SW17 Lifted hood microswitch (optional)
T1 Filter shaker timer
T2 Filter shaker timer 2
T3 Driver’s seat timer
T4 LPG safety timer (LPG3 version only)
TC Glow plug timer (D3 version only)
Colour codes
BK Black
BU Blue
BN Brown
GN Green
GY Grey
OG Orange
PK Pink
RD Red
VT Violet
WH White
YE Yellow
