USER MANUAL
ENGLISH
9097883000(1)2008-06 A SCRUBTEC 233 9
USE
WARNING!
On some points of the machine there are some adhesive plates indicating:
DANGER –
WARNING –
CAUTION –
CONSULTATION –
While reading this Manual, the operator must pay particular attention to the symbols shown on the plates.
Do not cover these plates for any reason and immediately replace them if damaged.
BEFORE MACHINE START-UP
1
2
9
3
9
12
18
14
P100308
Brush or pad-holder installation
NOTE
The machine is supplied with two brushes (A, Fig. 1) installed. According to the type of fl oor to be cleaned, it is possible
to replace the brushes (A) with the pad-holders with pads (B).
Lift the machine by prying the handlebar (2).1.
Install the brushes (A, Fig. 1), or the pad-holders with pads (B), in the 2 hubs of the deck (9).2.
Lower the machine by using the handlebar (2).3.
AB B
Figure 1
P100313
