ENGLISH USER MANUAL
14 SCRUBTEC 233 9097883000(1)2008-06 A
SQUEEGEE CLEANING, CHECK AND REPLACEMENT
NOTE
The squeegees must be clean and the blades must be in good conditions in order to get a good drying.
CAUTION!
It is advisable to wear protective gloves when cleaning the squeegees and the brush/pad-holder deck because
there may be sharp debris.
Drive the machine on a level fl oor.1.
Make sure that the power supply cable (10) is disconnected from the electrical mains.2.
To reach for the brush/squeegee-holder deck, lift the machine by using the handlebar (2).3.
Remove the squeegees from the deck by pressing the mounting springs (27).4.
Check the brush/squeegee-holder deck (9) and clean it, in particular, clean the compartments (A, Fig. 2) and the vacuum hole 5.
(B).
Wash and clean the squeegee. In particular, clean the compartments (C) and the vacuum hole (D) from dirt and debris.6.
Check that the blade (E) and the blade (F) are integral and free from cuts and lacerations; if necessary replace them.7.
Install the squeegees.8.
A
C
E
F
D
A
B
B
E
Figure 2
P100314
BRUSH CLEANING
CAUTION!
It is advisable to wear protective gloves when cleaning the brushes because there may be sharp debris.
Remove the brushes as shown in Use chapter.1.
Clean and wash the brushes with water and detergent.2.
Check the brush bristles for integrity and wear; if necessary, replace the brushes.3.
