Name
Controlled by
Characteristics
Comment
Related
pin
Do Aux PWM1
3D matrix with user
defined axis
6 amp for low speed
inductive load
Low sider driver
E83, Aux
PWM1
Do Aux PWM2
3D matrix with user
defined axis
2 amp for low speed
inductive load
Low sider driver
V90, Aux
PWM2
Do Aux PWM3
3D matrix with user
defined axis
2 amp for high speed
inductive load
Low sider driver
V56, Aux
PWM3
Do Aux PWM-x labels
All three Do Aux PWM-x is set up the same way.
 Do Aux PWM-x period
The period time of the PWM signal
 Do Aux PWM-x duty
A 3D matrix with the base duty
 Do Aux PWM-x duty out
The output from the matrix Do Aux PWM-x duty table is the input to
this matrix. The Aux PWM-x duty out table handles non linear behavior
of actuators.
 Flx Do Aux PWM-x duty X
User defined X-axis of the matrix
 Flx Do Aux PWM-x duty Y
User defined Y-axis of the matrix
 Flx Do Aux PWM-x duty Z
User defined Z-axis of the matrix
5.2 Going Online
When you have entered values for all parameters in Engine Setup you can
connect your PC to NIRA i7x. Follow the steps below before you attempt to
start the engine.
1. Turn on the ignition
