Example. (Make sure the Throttle is fully closed before you start)
When the throttle is fully opened.
App Ad Pot 1 = 87,3%
App Ad Pot 2 = 0,1%
When the throttle position is fully closed.
App Ad Pot 1 = 7,4%
App Ad Pot 2 = 0,1%
Enter following values
App Pot 1 Umsp = 87,3%
App Pot 2 Umsp = 0,1%
App Pot 1 Lmsp = 7,4%
App Pot 2 Lmsp = 0,1%
Switch the key off and then on again and check.
Engine Setup -> All Paramters-> App Position
The value should go from 0% to 100 % when opening the throttle.
Now the throttle sensor is calibrated.
7. Go back to the Mappings tab, select the Monitor Output folder and
the ”General” subfolder. Make sure all sensors are calibrated
correctly. If they are not, return to the Engine Setup tab, select the
Sensors folder and correct the problem.
ECT and MAT sensor values should show ambient temp, or else
they’re calibrated wrongly.
MAP should say approximately 100kPa, which is ambient pressure.
You can now start the engine. Select Toggle Dashboard under the Tools
menu in the main menu, or hit the F7 key. Crank the engine. You should see
the tach needle jump up to about 200 rpm or else the CKP sensor signal is
missing and you won’t be able to start the engine.
Your engine should start fairly quickly and show reasonable values on the
dash. If any instrument is showing an unreasonable value or if an Alarm icon
appears, something is wrong in one of the parameters in Engine Setup, or
the electrical installation is problematic.
Since the IAC hasn’t been calibrated yet, you may have to give a bit of gas in
order to keep the engine from stalling.
