NIVELCO MicroTREK - TECHNICAL DATA OF THE PROBES

BKI16ATEX0018X ♦ htk4014a0600p_03 ♦ 9 / 76
TECHNICAL DATA OF THE PROBES
TYPE
HK--
HL--
HV--
HW--
HR--
HP--
HS--
HZ--
HN--
HJ--
HT--
HU--
HD--
HE--
HA--
HB--
HC--
HH--
Denomination 4mm cable Rod Rod 8 mm cable 4mm twin cable Twin rod Coaxial
Max. measuring distance 24 m 3 m 6 m 24 m 24 m 3 m 6 m
Min. measuring distance
εr = 80 / εr = 2.4
0.3 m / 0.4 m 0.3 m / 0.4 m 0.3 m / 0.4 m 0.3 m / 0.4 m 0.15 m / 0.3 m 0.15 m / 0.3 m 0 m
Min. distance to objects
∅ 600 mm ∅ 600 mm ∅ 600 mm ∅ 600 mm ∅ 200 mm ∅ 200 mm ∅ 0 mm
Min. medium εr
2.1 2.1 2.1 2.1 1.8 1.8 1.4
1” BSP 1” BSP
1” NPT
1” BSP 1
1
/
2
” BSP 1
1
/
2
” BSP 1
1
/
2
” BSP 1
1
/
2
” BSP
1” NPT
1
1
/
2
” BSP
1
1
/
2
” BSP
Process connection
1
1
/
2
” NPT
1” NPT 1
1
/
2
” NPT 1
1
/
2
” NPT
1
1
/
2
” NPT 1
1
/
2
” NPT
1
1
/
2
” NPT
Probe material 1.4401 1.4571 1.4571 1.4401 1.4401 1.4571 1.4571
Nominal diameter of probe 4 mm 8 mm 14 mm 8 mm 4 mm 8 mm 28 mm
Mass 0.12 kg/m 0.4 kg/m 1.2 kg/m 0.4 kg/m 0.24 kg/m 0.8 kg/m 1.3 kg/m
Separator material – – – –
PFA, welded on
the cable
PTFE-GF25
if length > 1.5m
PTFE,
If length > 1.5m
Weight dimensions
∅ 25 x 100 mm
– –
∅ 40 x 260 mm ∅ 40 x 80 mm
– –
Weight material 1.4571 – – 1.4571 1.4571 – –
