DIMENSIONS
Mod.
T5S
275V
30VE
300V (VBS)
330V (VBS)
A
mm
470
470
470
550
550
B
mm
500
500
510
590 (660)
595 (665)
C
mm
720
720
730
710 (780)
750 (820)
D
mm
310
310
310
370
370
E
mm
530
530
530
600
635
F
mm
480
480
480
490
505
G
mm
630
630
630
670 (595)
710 (595)
H
mm
245
245
245
265
310
I
mm
245
245
245
295
350
TECHNICAL DATA
Mod.
T5S
275V
30VE
300V
(VBS)
330V
(VBS)
Blade
mm
250
275
300
300
330
Blade turns/1’
giri/min
310
310
310
310
300
Carriage movement
mm
275
275
275
300
300
Cut’s capacity Ø
mm
190
195
200
215
230
Cut’s capacity □
mm
190x270
195x250
200x230
215x280
230x300
Thickness adjuster
mm
13
13
13
12
12
Net weight
Kg
23
24
24.5
31
34
Motor single phase
kW
0.18
0.18
0.18
0.242
0.242
Motor three phase
kW
0.27
0.27
0.27
0.27
0.27
