Noaw TWS - Lubrication of Carriage Guide Bars; Lubrication of Transversal Guide Rods

Use and maintenance
64
7.3 Lubricating the guide bars of the carriage (weekly)
WARNING: Only use white vaseline oil.
DO NOT USE VEGETABLE OILS!
1. Move the carriage as close
as possible to the operator;
2. Insert the oiler in the special
hole;
3. Squeeze the oiler so that a
small amount of oil goes into
the hole;
4. Remove the oiler and slide
the carriage 3/4 times.
NB: Not all machines are
equipped with oiler screw If so,
lift the machine and lubricate
the carriage bar directly.
7.4 Lubricating the transversal guide rods of the plate and food press (weekly)
WARNING: Only use white vaseline oil.
DO NOT USE VEGETABLE OILS!
1. Put a small amount of oil on the rod and slide the group 3/4 times;
2. Clean as necessary removing any excess oil.
