Straight feed slicer for sausage
1. Feed cable
2. Identification plate, technical
data and EC marking
3. ON/OFF push button
4. Graduated knob for slice
thickness
5. Meat table
6. Unlocking lever for vertical
sliding
7. Food press maneuvering
lever
8. Blade
9. Sharpener knob
10. Slice deflector
11. Foot
12. Upper table
13. Meat table support
14. Plate blocking handle
15. Base
16. Blade guard ring
17. Sharpener cover
18. Gauge plate
19. Tie rod
20. Lubricating screw
21. Blade cover
22. Shoe
23. Plate pushing handle
