To access the programming mode, the machine must be ON and idle (between
cycles).
On the timer board, press and hold both the MOVE and ENTER buttons on the
timer board simultaneously for two seconds.
The PROGRAM (PGM) light and light A will illuminate.
NOTE: Once in the programming mode, the MOVE button is used to scroll
between the programming categories and the ENTER button is used to select
the category.
Press the MOVE button to move the solid light to the desired location of FILL,
RINSE AID, DETERGENT, or SANITIZER. Please note that options A, B, C and
D are not adjustable outputs.
Press the ENTER button for the chosen category. Now, the (PGM) light will
illuminate along with lights corresponding to the time values for the chosen
category. The ACCEPT light will blink.
The PROGRAM light will illuminate.
To change the value of a parameter, use the MOVE button to illuminate the
light next to the time option (time is measured in seconds). In the time cate-
gories, each second in use will light up. To deselect the option, press ENTER
and the light will go off, press ENTER again and it will illuminate. Once you
have set your time catergory, press the MOVE button until the ACCEPT light
illuminates and press ENTER. This will save the changed parameters.
Once you press the ENTER button when the ACCEPT light is blinking you will
exit the programming mode. To change any other values, you will have to re-
turn to the programming mode. To revert back to a previous setting, you must
return to that option and change the parameter back to the previous setting.
Once in the programming mode, if there have been no keypad inputs for
approximately two minutes, the system will automatically exit out of the pro-
gramming mode. Any changes to parameters will be saved when the program-
ming mode is automatically exited.
The wash and drain cycles are not adjustable.
All time adjustments are in seconds. Refer to the chart on the following page
for adjustable outputs.
