22
NOBLE UL30 CONTROL PANEL
PARTS
1
3
4
5
6
7
ITEM QTY DESCRIPTION PART NUMBER
1 1 W- Control Panel LT with Heater 05700-003-45-73
2 1 Timer, Universal Polytron 05945-003-33-09
3 2 Contactor, 115V, 30A 05945-109-05-69
4 1 Screw, 10-32 3/8” Long Phil Truss 05700-003-31-48
5 3 Locknut, 10 -24 S/S Hex w/ Nylon Ins. 05305-173-12-00
6 8 Heyco Open/Closed Busing .875 5975-003-35-21
7 2 Relay, 20A 5945-002-90-51
