Noble UL30 - PUMP & FEEDER SYSTEMS

28
PARTS
UH30 CHEMICAL FEEDER PUMP ASSEMBLY
1
9
10
8
6 7
4
3
5
2
ITEM QTY DESCRIPTION PART NUMBER
1 1 A-Peri Pump, 14 RPM 05700-002-72-82
2 1 A-Peri Pump, 36 PRM 240V/Red Tygoprene 05700-003-78-74
3 2 Strap, Nylon Loop 04320-002-71-22
4 1 CW 750 PE UV Black 8924 12” 05700-003-33-63
5 1 W Peripump Slide 05700-003-33-48
6 1 A-Stop Bracket 05700-003-36-24
7 2 Screw, 10-32 X 3/8” Long Phil Truss 05305-173-12-00
8 2 Tube Stiffener 05700-003-33-60
9 1 Tie, 4” PLT 1-M Panduit Cable 05700-003-33-58
10 1 A-Tube, Blue 1/4 X 22” Polyethylene
05700-011-86-78
