Nokia E5-00 User Manual

When the device is in the offline profile, you can still use WLAN (if available).
Remember to comply with any applicable safety requirements when establishing
and using a WLAN connection.
Tip: To check the unique media access control (MAC) address that identifies your
device, enter *#62209526# in the home screen.
WLAN wizard
Select Menu > Ctrl. panel > Connectivity > WLAN wiz..
The WLAN wizard helps you to connect to a wireless LAN (WLAN) and manage your
WLAN connections.
If the search finds WLANs, to create an internet access point (IAP) for a connection
and start the web browser using this IAP, select the connection and Start web
browsing.
If you select a secured WLAN, you are asked to enter the relevant password. To
connect to a hidden network, you must enter the correct network name (service set
identifier, SSID).
If you already have the web browser running using the currently active WLAN
connection, to return to the web browser, select Cont. web browsing.
To end the active connection, select the connection and Disconnect WLAN.
WLAN internet access points
Select Menu > Ctrl. panel > Connectivity > WLAN wiz. and Options.
Select from the following:
Filter WLAN networks — Filter out wireless LANs (WLANs) from the list of found
networks. The selected networks are not displayed the next time the application
searches for WLANs.
Connectivity 87

Nokia E5-00 Specifications

General

Display Type	TFT, 256K colors
Display Size	2.36 inches
Resolution	320 x 240 pixels
Operating System	Symbian OS 9.3, Series 60 v3.2 UI
CPU	600 MHz ARM 11
Internal Storage	250 MB
RAM	256 MB
Dimensions	115 x 58.9 x 12.8 mm
Weight	126 g
Announced	2010, April
Status	Discontinued
Network	GSM / HSPA
2G bands	GSM 850 / 900 / 1800 / 1900
Speed	HSPA 10.2/2 Mbps
GPRS	Class 32
EDGE	Class 32
SIM	Mini-SIM
Keyboard	QWERTY
GPU	No
Video	VGA@15fps
Alert types	Vibration; MP3, WAV ringtones
Loudspeaker	Yes
3.5mm jack	Yes
Bluetooth	2.0, A2DP
Radio	Stereo FM radio, RDS
USB	microUSB 2.0
Browser	WAP 2.0/xHTML, HTML, Adobe Flash Lite
Java	Yes, MIDP 2.1
Stand-by	Up to 635 h (2G) / Up to 670 h (3G)
Music play	Up to 38 h
Main Camera	5 MP
Battery	Li-Ion 1200 mAh
3G bands	HSDPA 900 / 2100
Card slot	microSD, up to 32 GB
WLAN	Wi-Fi 802.11 b/g
GPS	Yes, with A-GPS
Colors	Carbon Black, Chalk White, Sky Blue, Copper Brown, Silver Grey
Talk time	Up to 5 h (3G)
