Nokia E5-00 User Manual

Details — View the details of a network shown in the list. If you select an active
connection, the connection details are displayed.
Operating modes
There are two operating modes in Wi-Fi WLAN: infrastructure and ad hoc.
The infrastructure operating mode allows two kinds of communication: wireless
devices are connected to each other through a Wi-Fi/WLAN access point device, or
wireless devices are connected to a wired LAN through a Wi-Fi/WLAN access point
device.
In the ad hoc operating mode, devices can send and receive data directly with each
other.
WLAN settings
Select Menu > Ctrl. panel > Settings and Connection > Wireless LAN.
To have an indicator displayed when there is a wireless LAN (WLAN) available in
your current location, select Show WLAN availability > Yes.
To select the interval for your device to scan for available WLANs, and to update the
indicator, select Scan for networks. This setting is not available unless you select
Show WLAN availability > Yes.
To set the device to test the internet capability of the selected WLAN automatically,
to ask for permission every time, or to never perform the connectivity test, select
Internet connectivity test > Run automatically, Ask every time, or Never
run. If you select Run automatically or allow the test to be performed when the
device asks for it, and the connectivity test is performed successfully, the access
point is saved to internet destinations.
To check the unique media access control (MAC) address that identifies your device,
enter *#62209526# in the home screen. The MAC address is displayed.
88 Connectivity

Nokia E5-00 Specifications

General

Display Type	TFT, 256K colors
Display Size	2.36 inches
Resolution	320 x 240 pixels
Operating System	Symbian OS 9.3, Series 60 v3.2 UI
CPU	600 MHz ARM 11
Internal Storage	250 MB
RAM	256 MB
Dimensions	115 x 58.9 x 12.8 mm
Weight	126 g
Announced	2010, April
Status	Discontinued
Network	GSM / HSPA
2G bands	GSM 850 / 900 / 1800 / 1900
Speed	HSPA 10.2/2 Mbps
GPRS	Class 32
EDGE	Class 32
SIM	Mini-SIM
Keyboard	QWERTY
GPU	No
Video	VGA@15fps
Alert types	Vibration; MP3, WAV ringtones
Loudspeaker	Yes
3.5mm jack	Yes
Bluetooth	2.0, A2DP
Radio	Stereo FM radio, RDS
USB	microUSB 2.0
Browser	WAP 2.0/xHTML, HTML, Adobe Flash Lite
Java	Yes, MIDP 2.1
Stand-by	Up to 635 h (2G) / Up to 670 h (3G)
Music play	Up to 38 h
Main Camera	5 MP
Battery	Li-Ion 1200 mAh
3G bands	HSDPA 900 / 2100
Card slot	microSD, up to 32 GB
WLAN	Wi-Fi 802.11 b/g
GPS	Yes, with A-GPS
Colors	Carbon Black, Chalk White, Sky Blue, Copper Brown, Silver Grey
Talk time	Up to 5 h (3G)
