Introduction
Phone description
RAPIDO YAWE is the main digital baseband ASIC in the HW53. It contains functionality for both WCDMA and
GSM EDGE.
AVILMA is power management ASIC having voltage regulators and audio transceiver and BETTY is energy
management ASIC having charging switch and FBUS transceiver.
Memory components are internal COMBO 1 Gb/2 Gb and a card reader for MicroSD.
Function Description Item ref
EM ASIC AVILMA N2200
BETTY N2300
System ASIC RAPIDO YAWE D2800
Memory Combo 1Gb DDR + 2Gb NAND D3000
Camera accelerator Xena N1400
Display controller S1D13747 D2450
Back-up battery RTC BACKUP CAPAC 311 G2200
FM-radio with RDS BTHFMRDS2.3M module D6000
Bluetooth BTHFMRDS2.3M module D6000
WLAN WLAN module ENW49701N N6300
GPS GPS5350_ROM3.0 N6200
RF ASIC Vapaus N7500
GSM PA 850/900/1800/1900 N7520
WCDMA PA 850/900/1900/2100 N7540
Oscillator VCTCXO 38.4MHZ G7500
TCXO 38.4 MHz G6450
Crystal 32.768KHZ B2200
IO-expander BASIC IOExpander N2850
SIM card reader X2700
HS USB transceiver ISP1704 D3300
FM transmitter SI4713 N6150
TV out graphics engine S1D13771B D2480
Accelerometer AHTI_A 3-AXIS N6501
Magnetometer City compass N6510
RM-484; RM-485; RM-486
System Module and User Interface
Issue 1 COMPANY CONFIDENTIAL Page 8 –7
Copyright © 2009 Nokia. All rights reserved.
