RJ-230 Soldering jig
The jig is used for soldering and as a rework jig for the system module.
It is made of lead-free rework compatible material.
SA-131 RF coupler
SA-131 is a generic device for GPS testing. It is used together with
SS-62.
SA-154 RF coupler
SA-154 is an RF coupler for WCDMA and GSM RF testing. It is used
together with the product-specific flash adapter.
SS-182 Camera removal tool
The camera removal tool SS-182 is used to remove/attach a camera
module from/to the camera socket of the phone PWB.
Cables
The table below gives a short overview of service devices that can be used for testing, error analysis, and
repair of product RM-484; RM-485; RM-486. For the correct use of the service devices, and the best effort of
workbench setup, please refer to various concepts.
RM-484; RM-485; RM-486
Service Tools and Service Concepts
Page 2 –6 COMPANY CONFIDENTIAL Issue 1
