Nokia RM-484 - RF Testing Concept with RF Coupler

Type Description
SB-6 Bluetooth test and interface box
PKD-1 SW security device
SX-4 Smart card
Measurement equipment
PC with Phoenix service software
Cables
PCS-1 DC power cable
XCS-4 Modular cable
CA-56RS RF cable
CA-56RS RF tuning cable
GPIB control cable
USB cable
RF testing concept with RF coupler
Figure 12 RF testing concept with RF coupler
Type Description
Product specific devices
FS-113 Flash adapter
RM-484; RM-485; RM-486
Service Tools and Service Concepts
