Self test limits
•
Values in LSB
•
4605957 (ST, LIS3LV02DQ)
•
2.5V
•
x=(min 180, max 320)
•
y=(min 180, max 320)
•
z=(min 80, max 250)
•
2.8V, not evaluated
•
4605983 (ADI, AD22340)
•
2.5V not evaluated
•
2.8V
•
x=(min 15, max 30)
•
y=(min 15, max 30)
•
z=(min 3, max 15)
•
4605987 (ST, LIS302DL)
•
2.5V not evaluated
•
2.8V
•
x=(min 3, max 16), unsigned
•
y=(min 3, max 16), unsigned
•
z=(min 3, max 16), unsigned
Magnetometer troubleshooting
Equipment
•
Non-magnetic, horizontal table
•
nearest ferromagnetic part, distance more than 50 cm
•
Traditional needle type compass for reference
•
Rotating platform (sheet of wood or plastic)
•
PC with Phoenix
Preparation of phone
•
Set the rotating platform to the table
•
Set the phone and reference compass to the rotating platform
•
Connect the phone to the PC and start Phoenix
Tests
•
General troubleshooting test
•
Self-test (ST)
•
Azimuth check test
RM-484; RM-485; RM-486
BB Troubleshooting
Page 3 –30 COMPANY CONFIDENTIAL Issue 1
Copyright © 2009 Nokia. All rights reserved.
