ACCESS GATEWAY
A
Appendices 201
Appendices
Appendix A Signal Connection Arrangements
RJ-45 Ethernet Port
The Wireless Connect Gateway RJ-45 Ethernet port can connect to any networking devices that
use a standard LAN interface, such as a Hub/Switch Hub or Router. Use unshielded twisted-
pair (UTP) or shield twisted-pair (STP) cable to connect the networking device to the RJ-45
Ethernet port.
Depending on the type of connection, 10Mbps or 100Mbps, use the following Ethernet cable,
as prescribed.
10Mbps: Use EIA/TIA-568-100-Category 3, 4 or 5 cables.
100Mbps: Use EIA/TIA-568-100-Category 5 cable.
Figure 199 RJ-45 Connector and Cable Pins
Note: To prevent loss of signal, make sure that the length of any twisted-pair connection does not
exceed 100 meters.
Appendix B Regulations/EMI Compliance
FCC Regulatory Statement
Part 15-Class B compliant device
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
conditions:
