NORDAC PRO (SK 500P) ā Users Manual for Frequency Inverters
8 BU 0600 en-2319
1 General
The NORDAC PRO (SK 500P - SK 550P) series is based on the tried and tested NORD platform. The
frequency inverters are characterised by their compact design and optimum control characteristics,
and have uniform parametrisation.
The frequency inverters have sensorless current vector control with a wide range of settings. In
combination with suitable motor models, which always provide an optimised voltage/frequency ratio,
all three-phase asynchronous motors that are suitable for inverter operation and permanently excited
synchronous motors can be driven. For the drive unit, this means very high starting and overload
torques with constant speed.
The power range is from 0.25 kW to 5.5 kW.
This series of frequency inverters can be adapted to individual requirements by means of modular
assemblies.
This manual is based on the device software as stated in the version list (see P707). If the frequency
inverter uses a different software version, this may cause differences. If necessary, the current manual
can be downloaded from the Internet (http://www.nord.com/
).
Additional descriptions exist for optional functions and bus systems (http://www.nord.com/).
Accessories
The accessories that are mentioned in the manual are also subject to changes. Current details of
these are included in separate data sheets, which are listed under www.nord.com
under the heading
Documentation ā Manuals ā Electronic drive technology ā Techn. Info / Data sheet. The data
sheets available at the date of publication of this manual are listed by name in the relevant sections
(TI ...).
