Nordson 3100V Series Customer Product Manual

Tank
B
3-1
Section
B
3
Tank
1.
lntroduction
2.
Overview of the Tank
WARNING: Allow only
qualified personnelto perform
the
following
tasks.
Follow
the safety
instructions
in this document
and all other related
documentation.
This section describes
how to replace the tank and manifold. lt includes
.
an overview
of
the
tank assembly
o
procedures
for replacing the
tank
and manifold
o
parts
lists for the tank
assembly and unit frame
Refer to the following sections for additional information
on the tank and
manifold:
Description
gives
tank specifications, including
the
tank capacity,
the tank volume, and
the dimensions of the tank lid opening.
a
a
Operation
gives
the
procedure
for filling the tank with adhesive.
Maintenance
gives procedures
for flushing
the tank and
manifold
and
for
draining adhesive from the tank.
Hydraulics includes
the
manifold
assembly
parts
list.
Controlincludes
procedures
for replacing the tank resistance
temperature detector
(RTD)
or thermostat.
The tank holds
a supply of adhesive and melts it
before
it is
pumped
to
the hoses and
guns.
An RTD
and overtemperature thermostat sense the
tank temperature
and
provide
input to the control system. The
tank
is
heated
by cast-in heating elements.
a
a
a
@
2000 Nordson
Corporation
All dghts reseryed
41-3000v
lssued
5/00
83EN-05-[3V-4-AXXXI-2
