lnstallation
A
3-13
5.
Remove
the
O-ring
plug
from the hose
port
where
you
plan
to
install
the first hose.
Keep the
O-ring
plug
for later use during maintenance
and
servicing
procedures.
6. See Figure A
3-8. Take one of
the hose-connector
fittings
that
was
shipped
with the
unit and apply an
anti-seize
compound
to the
threads. Thread
the fitting into
the hose
por1.
41033984
Fig. A 3-8
Threading
the Hose Connector Fitting into
the
Hose Port
7. Tighten
the fitting with
a
wrench
8. Connect a hose
to the fitting.
Use two
wrenches
to tighten the hose
as shown in Figure
A3-7.
9.
lnstall
any additional
hoses by repeating
steps 4-8. Be sure to
connect a
second hose next
to the first, working from right to left.
Depending
upon
your
unit,
you
can connect a maximum
of
four
or six
hoses
this way.
