CRC200R USER GUIDE ISSUE 02
5-5
Display Action
V
e
r
i f y
C
a
r
d
s
C
a
r
d
I d
x
:
Type the number of the card index against which the card to be
verified is stored and press
Example Result (Mode 210):
V
e
r
i f y
: 0
0
0
1
C : 0 0 0 8 0 0 1
This display indicates that the card stored against Index 0001 is card
number 80 and is assigned Access Level 1 (in Extended Time Zone
operating mode). If capture is activated on either of the readers, this
is indicated by a C1 (capture at reader 1) and/or C2 (capture at
reader 1).
Example Result (Line mode):
V
e
r
i f y
: 0
0
0
1
C : 0 0 0 8 0 1
0
This display indicates that the card stored against Index 0001 is card
number 80 and is set to time zone 1 for reader 1 and time zone 0 for
reader 2.). If capture is activated on either of the readers, this is
indicated by a ‘C’ to the right of the time zone value.
Note 1: In W26 format, the card number is shown as site code and card number separated by a
colon (:).
Continue to press
to step through the card numbers incrementally. Press
to return to the
beginning of the “Verify Cards” menu item, so that you can enter another index number. Press
to escape this menu item followed by
to move to the next menu item.
5.4 Set PIN Code
This menu item enables you to set up to 10 (0 to 9) 4-digit PIN codes for use with a suitable
keypad or keypad/reader combination connected.
This menu item is selected when
is pressed in ‘Verify Cards’ and then
is pressed once.
To reach this menu item from the initial display, press
once and then press repeatedly until
the following screen is displayed:
S
e
t
P
I
N
C
o
d
e
Press
and carry out the following procedure:
Display Action
S
e
t P
I N
C
o
d
e
P
i n
0
: x
x
x
x
x
Type in the PIN number for PIN location 0 and press
S
e
t P
I N
C
o
d
e
P
i n
1
: x
x
x
x
x
Type in the PIN number for PIN location 1 and press
