MX40 Pro LED Display Controller User Manual
www.novastar.tech
3
Inputs (INPUT area)
Type
Qty
Description
HDMI 2.0-1 IN
1
Resolutions
Max resolution: 4096×2160@60Hz or 8192×1080@60Hz
Min resolution: 800×600@60Hz
Max
width/height
Max width: 8192 pixels (8192×1080@60Hz)
Max height: 8192 pixels (1080×8192@60Hz)
Frame rates
23.98/24/25/29.97/30/47.95/48/50/59.94/60/71.93/72/75/100/119.88/
120/143.86/144/240 Hz
HDR
Support HDR10 and comply with the SMPTE ST 2084 and SMPTE
ST 2086 standards.
Support HLG and comply with the BT.2100 standard.
EDID
management
Support standard resolutions, up to 3840×2160@60Hz.
Support custom input resolutions.
HDCP
HDCP 2.2 compliant, backwards compatible
Interlaced
signal inputs
Not supported
HDMI 2.0-2 IN
1
Resolutions
Max resolution: 4096×2160@60Hz or 8192×1080@60Hz
Min resolution: 800×600@60Hz
Max
width/height
Max width: 8192 pixels (8192×1080@60Hz)
Max height: 7680 pixels (1080×7680@60Hz)
Frame rates
23.98/24/25/29.97/30/47.95/48/50/59.94/60/71.93/72/75/100/119.88/
120/143.86/144/240 Hz
HDR
Support HDR10 and comply with the SMPTE ST 2084 and SMPTE
ST 2086 standards.
Support HLG and comply with the BT.2100 standard.
EDID
management
Support standard resolutions, up to 3840×2160@60Hz.
Support custom input resolutions.
HDCP
HDCP 2.2 compliant, backwards compatible
Interlaced
signal inputs
Not supported
HDMI 2.0-3 IN
1
Resolutions
Max resolution: 4096×2160@60Hz or 8192×1080@60Hz
Min resolution: 800×600@60Hz
Max
width/height
Max width: 8192 pixels (8192×1080@60Hz)
Max height: 7680 pixels (1080×7680@60Hz)
Frame rates
23.98/24/25/29.97/30/47.95/48/50/59.94/60/71.93/72/75/100/119.88/
120/143.86/144/240 Hz
