MX40 Pro LED Display Controller User Manual
www.novastar.tech
4
HDR
Support HDR10 and comply with the SMPTE ST 2084 and SMPTE
ST 2086 standards.
Support HLG and comply with the BT.2100 standard.
EDID
management
Support standard resolutions, up to 3840×2160@60Hz.
Support custom input resolutions.
HDCP
HDCP 2.2 compliant, backwards compatible
Interlaced
signal inputs
Not supported
DP 1.2
1
Resolutions
Max resolution: 4096×2160@60Hz or 8192×1080@60Hz
Min resolution: 800×600@60Hz
Max
width/height
Max width: 8192 pixels (8192×1080@60Hz)
Max height: 8192 pixels (1080×8192@60Hz)
Frame rates
23.98/24/25/29.97/30/47.95/48/50/59.94/60/71.93/72/75/100/119.88/
120/143.86/144/240 Hz
EDID
management
Support standard resolutions, up to 3840×2160@60Hz.
Support custom input resolutions.
HDCP
HDCP 1.3 compliant
Interlaced
signal inputs
Not supported
12G-SDI IN
1
Standards
Support ST-2082 (12G), ST-2081 (6G), ST-424 (3G) and ST-292
(HD) standard video inputs.
Support 3G-Level A/Level B (DS mode).
Resolutions
Max resolution: 4096×2160@60Hz
Frame rates
Support frame rates up to 60 Hz.
Outputs (OUTPUT area)
Type
Qty
Description
1–20
20
Gigabit Ethernet output ports. Support hot backup between Ethernet ports.
Max loading capacity per port:

8bit@60Hz: 650,000 pixels

10bit@60Hz: 480,000 pixels (available only with the A10s Pro receiving card)

10/12bit@60Hz: 325,000 pixels
OPT 1–4
4
10G optical output ports

OPT 1 transmits the data of Ethernet ports 1 to 10.
OPT 3 is the copy channel of OPT 1.

OPT 2 transmits the data of Ethernet ports 11 to 20.
OPT 4 is the copy channel of OPT 2.
HDMI 2.0-1 LOOP
1
HDMI loop through
HDMI 2.0-2 LOOP
1
