(4) "Pd": Foot Pedal check
Press Forward/Reverse Selector Switch, and Indicator will change. During normal time,
Indicator changes in hexadecimals ( 0~9, A~F ) according to the amount of depressing
Foot Pedal . Also, depressing the pedal slightly lights Reset Lamp, and depressing it fully
extinguishes the lamp. If Indicator does not change smoothly or Reset Lamp does not
light properly, Foot Pedal may be faulty. To cancel this check, press Forward/Reverse
Selector Switch again.
(5) "in": Initializing function
Press Forward/Reverse Selector Switch, and beeps will be made and rotation direction,
HAND/FOOT and other settings will return to the factory set condition.
Rotation direction: FWD (forward)
HAND/FOOT: HAND
Vacuum-coupled mode: OFF
(3)
"HL": Motor signal check (Hall IC check)
Press Forward/Reverse Selector Switch, and Indicator will indicate one or two
horizontal lines. Turn the motor slowly by hand, and this display will change to one line, two
lines, one line, two lines, smoothly from the top to bottom or from the bottom to top. If any
one of the three lines does not light, the sensor (Hall IC) in the motor is faulty or the cord is
severed, therefore repair is needed. To cancel this check, press Forward/Reverse Selector
Switch again.
Eg.
11
11
11
11
7
7
7
7
7
3
3
2 3 4 A b C d C b A 4 3 2
4
7
On some dental tables with vacuum dust collector, the motor may be used while being coupled
with a dust collector. When such a dust collector * is used, power consumption of ULTIMATE
XL can be regulated so that the vacuum-coupled function can work. If you need coupling with
a vacuum dust collector, select the mode as follows:
How to select the mode
While pressing Forward/Reverse Selector Switch, turn on Power Switch, and the mode
can be selected. A long beep indicates vacuum-coupled mode and 2 short beeps indicate
non-coupled (energy-saving) mode.
* Each time the switch selection is made, the mode changes between vacuum-coupled mode
and non-coupled mode.
* A currently known dust collector is KAVO EWL-560.
10. Vacuum-coupled Mode
