NTI ENTERPRISE ENVIRONMENT MONITORING SYSTEM
19
View Remote Digital Inputs
The View Remote Digital Inputs selection will show the present status of each dry contact sensor connected to expansion devices
(i.e. E-DI16DO16) connected to the ENVIROMUX.
The current value being reported by the sensor and the state (whether Normal or Alert) will be shown. If the sensor is in alert
status, pressing the <Enter> key would provide the option to either acknowledge the alert or dismiss it.
Figure 13- Text Menu-View Remote Digital Inputs
View Remote Output Relay
The View Remote Output Relay selection will show the present state of the Remote Output Relays connected to the ENVIROMUX
through expansion devices (i.e. E-DI16DO(R)16). To manually change its state, press <Enter> and select between Inactive and
Active.
Figure 14- Text Menu-View Remote Output Relays
