NTI ENTERPRISE ENVIRONMENT MONITORING SYSTEM
47
Authentication Settings
Security in the ENVIROMUX can be managed one of two ways; through the local settings (passwords assigned in user settings on
page 43) or through an LDAP server. If security is configured to use LDAP mode, then the passwords for users must be those
found on a configured LDAP server.
Select “Authentication Settings” from the list and press <Enter>. A menu providing an option to either user Local authentication
or LDAP mode. When in LDAP mode, usernames on the LDAP server must match those in the user settings of the ENVIROMUX
or access will be denied.
Note: When the root user logs with the ENVIROMUX in LDAP mode, if the LDAP server is not responding, local
authentication will be tried.
Figure 56- Text Menu-Authentication Settings
User Authentication
Mode Select Local to use authentication based on passwords in the ENVIROMUX user configuration
Select LDAP to use authentication based on passwords in an LDAP server
Primary LDAP Server Enter Hostname or IP address of Primary LDAP Server
Secondary LDAP Server Enter Hostname or IP address of Secondary LDAP Server (optional)
LDAP Server Type Tab to choose from the following:
Generic LDAP server
Novell Directory server
Microsoft Active Directory
LDAP Service Base DN Enter the Base DN for users (ex: ou=People,dc=mycompany,dc=com)
Even though LDAP authentication is being used, each user must also have a local account. User permission level is established
by the local account.
Press <Tab> to highlight Save and press <Enter> to save before pressing <Esc> to exit.
