Jetson Nano Platform Adaptation and Bring-Up Guide DA_09361-002 | 11
A string containing the name of the function to mux to the pin or group. It must be
one of these values:
● xusb
● pcie-x1
● pcie-x4
Take Table 2, for example. Create a PCIe subnode and property under xusb_padctl
based on the device tree structure described above:
xusb_padctl@7009f000 {
...
pcie {
status = "okay"
lanes {
pcie-0 {
status = "okay"
nvidia,function = "pcie-x1";
};
pcie-1 {
status = "okay"
nvidia,function = "pcie-x4";
};
pcie-2 {
status = "okay"
nvidia,function = "pcie-x4";
};
pcie-3 {
status = "okay"
nvidia,function = "pcie-x4";
};
pcie-4 {
status = "okay"
nvidia,function = "pcie-x4";
};
pcie-5 {
status = "okay"
nvidia,function = "xusb";
};
pcie-6 {
status = "okay"
nvidia,function = "xusb";
};
};
...
};
Note:
UPHY lane 0 and UPHY lane 5 are not exposed, and can only be assigned to the
pcie-x1 and xusb functions.

Nvidia JETSON NANO Specifications

General

GPU	128-core NVIDIA Maxwell
Memory	4 GB LPDDR4
Storage	16 GB eMMC 5.1
Video Encode	4K @ 30 | 4x 1080p @ 30 | 9x 720p @ 30 (H.264/H.265)
Dimensions	100 mm x 80 mm x 29 mm
CPU	Quad-core ARM Cortex-A57
Video Decode	4K @ 60 | 2x 4K @ 30 | 8x 1080p @ 30 | 18x 720p @ 30 (H.264/H.265)
Connectivity	Gigabit Ethernet
Display	HDMI 2.0
USB	USB 3.0
Other	GPIO, I2C, SPI, UART
Operating System	Linux
Power	5V
Camera	12x (MIPI CSI-2) DPHY lanes
