4: Sample Experiments
Configuring for a Combination of Two Time Channels
Configure a time acquisition process for a combination of two time channels (if desired) by selecting the
Combination 1 tab on the Time Acquisition Channel Configuration screen.
►
Procedure
Perform the steps below to configure a combination:
1. Select Enabled to set the time acquisition calculation for the wavelength.
2. Enable Plotted to see a real-time graph of the acquired data in a spectral window.
3. Specify Time Channel A through F for the First Channel.
4. Select the mathematical operation to produce the data for Combination 1.
5. Specify Time Channel A through F for the Second Channel.
6. Select a multiplicative factor to apply to the data before plotting or storing. Then, select an
additive constant or offset to apply to the data. OOIBase32 applies the additive constant or offset
after applying the factor but before plotting or storing data.
The equation for the Factor and Offset functions is: Results = (Factor * Data) + Offset
7. Configure a time acquisition process for the Combination 2 page, if desired. This page is virtually
identical to the Combination 1 page, with the exception that you can choose Combination 1 for
the first or second channel in Combination 2.
8. Click the Apply button to apply the changes, and then click the OK button to close the Time
Acquisition Channel Configuration screen.
9. Proceed to the
Configuring the Time Acquisition Configuration Screen section below.
Configuring the Time Acquisition Configuration Screen
► Procedure
1. Select Time Acquisition | Configure | Configure Acquisition from the menu bar to open the Time
Acquisition Configuration screen.
