2.3 Customer/Vendor Display
There are two displays on the scale, one is on the vendor side and the other is on the
customer side.
These two LCD displays incorporate LED backlight. Both the customer and vendor
displays show 5 digits of weight, 5 digits of tare, 7 digits of unit price and 7 digits of total
price values along with cursors for Zero, Net and Prepack mode. Both the customer
and vendor displays can also show 16 alphanumeric characters for commodity
description, marquee and prompt messages during programming.
The Weight and Total Price display characters are 12mm high by 7.4mm wide. The
Tare and Unit Price display are 10mm high by 6mm wide. The alphanumeric
characters are 7.6mm high and 5mm wide.
Another display option available is the full dot matrix display, which can enable
promotional graphical displays as well as special offers to increase in-store sales.
The Display Legends Definitions are shown in the following Table.
Cursor Definition
NET Indicates a tare has been entered and the weight is net.
ZERO Indicates scale at zero, i.e. within 1/4 increment.
PREPACK Indicates Pre-pack mode has been selected.
