C3600n User’s Guide
104
7. Look into the printer to check whether any sheets of paper are
visible on any part of the belt unit.
8. Remove any sheets of paper as follows:
• To remove a sheet with its leading edge at the front of the
belt, carefully lift the sheet from the belt and pull it forwards
into the internal drum cavity and withdraw the sheet.
paper jam belt_F8_07.jpg
• To remove a sheet from the central area of the belt, carefully
separate the sheet from the belt surface and withdraw the
sheet.
Paper Jam fuser In_F8_08.jpg
CAUTION!
Do not use any sharp or abrasive objects to separate
sheets from the belt. This may damage the belt surface.
To Next Page
