C3600n User’s Guide
106
• Holding the complete assembly by its top center, lower it into
place in the printer, locating the pegs at each end into their
slots in the sides of the printer cavity.
10. Lower the top cover but do not press down to latch it closed yet.
This will protect the drums from excessive exposure to room
lighting while you check the remaining areas for jammed sheets.
11. Open the rear stacker and check for a sheet of paper in the rear
path area.
Paper Jam Back_F8_09.jpg
• Pull out any sheets found in this area.
• If the sheet is low down in this area and difficult to remove, it
is probably still gripped by the fuser. In this case raise the top
cover, reach around and press down on the fuser pressure
release lever (1).
Paper Jam fuser release_F8_08.jpg
12. If you are not using the rear stacker, close it once paper has been
removed from this area.
