- 18 -
2. Setting Up
Unpacking and Installing the Machine
This section describes how to unpack and install the machine.
• Use extra care when handling the image drum (the green cylinder), because it is fragile.
• Do not expose the image drum to direct sunlight or strong light (approximately 1,500 lux or more). Even under room
lighting, do not leave the image drum for 5 minutes or more.
• Packaging and cushioning materials are required for transporting the machine. Do not dispose of it, and keep it for
future use.
1
Remove the machine from the box, and then remove accessories, cushioning
materials and the plastic bag from the machine.
2
Lift the machine, and then place it where it is to be installed.
3
Remove the protection tapes, protective sheet, and desiccant packs.
4
Press the button (A) and open the output tray (a) until it stops.
Injury may result.
Lift this machine by 2 persons, because it weighs approximately 23 kg.
To Next Page
