Oki C532 - Rear View; Inside of the Machine

- 53 -
3. Basic Operations
Rear View
Symbol Name
a Rear output tray
b Power connector
c Interface connector cover
d Network interface connector
e USB interface connector
Inside of the machine
Symbol Name
a LED head
b Fuser unit
c Toner cartridge / Image drum (Y: yellow)
d Toner cartridge / Image drum (M: magenta)
e Toner cartridge / Image drum (C: cyan)
f Toner cartridge / Image drum (K: black)
gTray 1
