3.3 Packing
(1) Packing Configuration
(a) Supplies Installed in C911/C931/C941/Pro9541WT
Transfer belt unit, fuser unit, waste toner box,
Black/yellow/magenta/cyan image drum cartridges,
Black/yellow/magenta/cyan toner cartridges
(b) Accessories
(1) light shield bags（4 pcs）
(2) AC power cable （At least 1 pcs）
(2) Packing
(a) Packing Unit: Individual
(b) Package Size: 760W x 824D x 973H (including pallet)
(c) Package Weight (Gross): Approx. 116 kg (C911/C931), 136kg (C941/Pro9541WT)
(3) Transport Condition
Packages that can be Piled: 4 high
3.4 Others
(1) Maintainability
(a) Installation
The installation of C911/C931/C941/Pro9541WT can be completed, without danger, by
nonengineers after it is shipped from a place where it was manufactured.
(b) User Maintenance
Replacement of Consumables and User-replaceable Units:
(1) Toner cartridges (black, yellow, magenta, cyan, white and clear)
(2) Image drums (black, yellow, magenta, cyan, white and clear)
(3) Fuser unit
(4) Transfer belt unit and 2nd transfer roller
(5) Waste toner box
General User Maintenance
(1) Paper jam removal
(2) LED head cleaning
(1) Parts Replaced Regularly
(a) Feed roller (user-replaceable parts, tray/MPT)
