Replacing consumables and maintenance unit
- 74 -
IndexTroubleshooting
1
2
Maintenance
6
Lift Section A, release the claws in the
direction shown in gure, and remove
the paper feed rollers (
).
7
Pinch the claws (two places) and
remove the separator (
). Open
Section B, and remove the separation
rollers (
).
To Next Page
