2-47 Using the EFI Densitometer ED-100
C9800 Color Guide - 47
Calibrating the Fiery with the ED-100
You can use ColorWise Pro Tools in conjunction with the ED-100 to calibrate the
Fiery.
TO CALIBRATE THE FIERY USING THE ED-100
1. Start Calibrator.
For instructions on starting Calibrator, see page 2-38.
2. Choose EFI Densitometer ED-100 as the measurement method.
3. In the Check Print Settings pane, choose the desired calibration set.
Choose the appropriate calibration set for the type of media you will use most often.
NOTE: For this calibration to take effect, the calibration set must be associated with one
or more output profiles. There is no need to make any new associations for the default
calibration set, since it is already associated with the default output profile.
4. In the Generate Measurement Page pane, click Print.
The Print Options dialog box appears.
5. Choose the appropriate options and click Print.
For Page Type, choose 21 Sorted Patches.
Sorted patches are printed on the page in the
order of their hue and saturation levels.
Paper Size is automatically set to LTR/A4 for
21 Patches.
For Input Tray, specify the paper source for
printing the measurement page.
6. Retrieve the measurement page from the
printer.
