2-50 Color Calibration
C9800 Color Guide - 50
Calibrating the Fiery with the DTP41
Using the ColorWise Pro Tools Calibrator application and the DTP41
spectrophotometer, you can quickly measure color patches printed by the C9800 and
automatically download these measurements to the Fiery.
NOTE: Before using ColorWise Pro Tools and the DTP41 to calibrate the Fiery, follow
the instructions on page A-87 for calibrating the DTP41 spectrophotometer.
TO CALIBRATE THE FIERY USING THE DTP41
1. Start Calibrator.
For instructions on starting Calibrator, see page 2-38.
2. Choose X-Rite DTP41 as the measurement method.
3. In the Check Print Settings pane, choose the desired calibration set.
Choose the appropriate calibration set for the type of media you use most often.
NOTE: For this calibration to take effect, the calibration set must be associated with one
or more output profiles. There is no need to make any new associations for the default
calibration set, since it is already associated with the default output profile.
4. In the Generate Measurement Page pane, click Print.
The Print Options dialog box appears.
5. Choose the appropriate options, and click Print.
For Page Type, choose either 21 or 34 Sorted
Patches.
Paper Size is automatically set to LTR/A4 for
21 Sorted Patches, or 11
x17/A3 for 34 Sorted
Patches.
For Input Tray, choose the paper source for
printing the measurement page.
