2-53 Calibrating the Fiery with the DTP32
C9800 Color Guide - 53
Calibrating the Fiery with the DTP32
Using the DTP32, you can quickly measure color patches and download these
measurements to the Fiery using ColorWise Pro Tools Calibrator.
NOTE: Before using ColorWise Pro Tools and the DTP32 to calibrate the Fiery, follow
the instructions on page A-93 for calibrating the DTP32 densitometer.
TO CALIBRATE THE FIERY USING THE DTP32
1. Start Calibrator.
For instructions on starting Calibrator, see page 2-38.
2. In the Select Measurement Method pane, choose X-Rite DTP32.
3. In the Check Print Settings pane, choose the desired calibration set.
Choose the appropriate calibration set for the type of media you will use most often.
NOTE: For this calibration to take effect, the calibration set must be associated with one
or more output profiles. The default calibration set is already associated with the
default output profile, so there is no need to make any new associations.
4. In the Generate Measurement Page pane, click Print.
The Print Options dialog box appears.
5. Choose the appropriate options, and click Print.
For Page Type, choose either 34 or 21 Sorted
Patches.
Paper Size is automatically set to LTR/A4 for
21 Sorted Patches, or 11
x17/A3 for 34 Sorted
Patches.
For Input Tray, specify the paper source.
6. Retrieve the measurement page from the
printer.
7. Click Measure in the Get Measurements pane.
The Measurement Options dialog box displays the specified Page Type and Paper Size
options.
