Oki MC562w Maintenance Manual

44952001TH Rev.2
5-7
Oki Data CONFIDENTIAL
5. MAINTENANCE MENUS
Item1 Item2 Item3 Item4 Item5 Value
Default
value
ODA
Default
value
OEL
Default
value
JP
Notes
Password Scanner
Maintenance
Mechanical
Tes t
FBS Test Speed Color 300x300dpi
Color 300x600dpi
Color 600x600dpi
Mono
Conduct mechanical testing (without reading an image).
ADF : Test moving original document (stops when set document has been moved)
May choose from single- or double-sided feeding.
FBS : CIS moving test (stops after designated number of operations)
Use fastest read speed (40 cpm).
Display"Testing"duringexecution?
→
Onthepanel,indicatecurrentnumberofexecutionsusingthemessage"Testno.xxx
underway."
TImes 0~65535
Execute --results--
Test no. xxx underway
Sensor
Tes t
Examples of this display are
shown below:
①
MEDIA H/L
②
SCAN H/L
③
REVERSE H/L
④
ADF CVR H/L
⑤
FB H/L
Display sensor status (H/L) in real time. Change the content of the display as needed
when the sensor status displayed changes.
①
Set-document detection sensor (MEDIA)
②
Scanning sensor (SCAN)
③
Reverse sensor (REVERSE)
④
ADF cover-open senor (ADF CVR)
⑤
FB home-position sensor (FB HP)
ADF Motor
Tes t
Forward
Forward Continuous
Reverse
Reverse Continuous
Test the ADF motor
①
After a short press of the button, rotate in the CW direction for 10 seconds and then stop.
②
After a long press of the button, rotate in the CW direction continuously. Stop when the
Stop button is pressed.
③
After a short press of the button, rotate in the CCW direction for 10 seconds and then
stop.
④
After a long press of the button, rotate in the CCW direction continuously. Stop when the
Stop button is pressed.
Deemed successful at all times. No need to display results.
Display"Testing"duringexecution?
→
Display a message on the panel showing that testing is underway.
Solenoid
Tes t
Once
Continuous
After a short press of the button, intake for 2 seconds and then stop.
After a long press of the button, intake for 2 seconds and stop for 3 seconds repeat.
Stop when the Stop button is pressed.
Deemed successful at all times. No need to display results.
Display"Testing"duringexecution?
→
Display a message on the panel showing that testing is underway.

Oki MC562w Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	LED
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Copy Resolution	600 x 600 dpi
Scan Type	Flatbed, ADF
Scan Resolution	Up to 1200 x 1200 dpi
Fax Speed	33.6 kbps
Paper Capacity	250 sheets
Connectivity	USB, Ethernet, Wi-Fi
Operating System Compatibility	Windows, Mac OS
Maximum Paper Size	A4
Mobile Printing	Google Cloud Print, Apple AirPrint
Fax Transmission Speed	Approximately 3 seconds per page
