2. DESCRIPTION OF OPERATION
Counter specifications
Total page count MPT page count Tray 1 page count Tray 2 page count Color page count Monochrome page count
Description Total number of
prints
Number of print media
hopped from MPT
Number of print media
hopped from Tray 1
Number of print media
hopped from Tray 2
Total number of color prints Total number of monochrome
prints
Count method:
A4-basisorsize
independence
Count up after
passing the writing
sensor
Count up if MPF (MPT)
hopping is finished
successfully
Count up if Tray 1
hopping is finished
successfully
Count up if Tray 2
hopping is finished
successfully
The number of print media passing
the fuser in color mode is counted
wheneachjobisnished(1*).
The value is counted on an A4/
Letter basis. Refer to A4/Letter
conversion table (on the next
page).
The number of print media passing
the fuser in monochrome mode is
countedwheneachjobisnished
(1*).
Printing speed for color mode
may be applied to monochrome
mode. The value is counted on an
A4/Letter basis. Refer to A4/Letter
conversion table (on the next
page).
peration when
paperhasjammed
Printedpagesarenotcountedwhenapaperfeed(hopping)jamorafeedjam(380)occurs.
Printedpagesarecountedwhenanyjamexceptthesaidjamsoccurs.
Since the total page count is incremented when the front end of print media passes the writing
sensor,afeedjam(380)isalsoincludedintothelimitsoncountsaccordingtoitsjamtype.
Ifpaperjamsbeforepassingthefuser,itspagesarenotcounted.If
paperjamsafterpassingthefuser,itspagesarecounted.
Operation for
Duplex
Front/back count
(+2)
Onlyfrontcount(+1) The count increases by two.
If a color page and a monochrome page exist in a pair of two pages,
the color page count increases by one, and the monochrome page
count increases by one. If a pair of two pages is in color, the color page
count increases by two. If a pair of two pages is in monochrome, the
monochrome page count increases by two.
Reset condition None None (1) Replacement of ROM with another one of a different version
(2) Change of the shipping destination
(3) Execution of MENU RESET of the system maintenance menu
(4) Replacement of a CU/PU board
Value storage
destination
PU PU PU PU CU CU
Menu/MenuMap
output
(*2)
EngineMenuMap
output
(*3) (*3) (*3) − −
*1. Eachofthecountisupdatedattheendofeachjoboreachoffourpages;however,thecountisnotupdatedifthepoweristurnedoffwhenanypagefrompageonethroughpagethree
ofajoboffourormorepagesisbeingprinted.
*2. It is shown in the header of MenuMap.
*3. EngineMenuMap outputs Engine Menu Print (the first page) and Engine EEPROM Dump Print (the last page), and the number of sheets of paper fed from each tray is described only in
the latter one (DUMP page only).
