SETTING ITEMS (ADMIN)
- 306 -
4
Specify the following items as required and
press [Next].
• When you press [EAP USER NAME], [PASSWORD],
or [RETYPE PASSWORD], the on-screen keyboard is
displayed.
For details of the on-screen keyboard, see the
following page:
P.320 "On-screen keyboard"
5
Confirm the settings and press [APPLY
NOW].
“NETWORK INITIALIZING” is displayed at the lower left
of the screen and this equipment starts initializing the
network interface card to apply the changes. This
message disappears when the setting is complete.
Error messages
The following error messages may be displayed on the touch
panel.
When you selected other than [EAP-TLS]:
When you selected [EAP-TLS]:
Item name Description
EAP USER NAME Press this button to enter the EAP
user name.
PASSWORD Press this button to enter the
authentication password.
RETYPE
PASSWORD
Press this button to enter the
authentication password again.
Use Username
from Common
Name in the User
Certificate
To set the common name in the
user certificate installed in this
equipment as EAP user name,
press [ENABLE].
Note
• If you set this item to [ENABLE],
you will not be able to enter
[EAP USER NAME].
Message Cause
[802.1X] Auth Server/Switch
couldn’t be contacted
• The RADIUS server
service is stopped.
• Configuration for the
RADIUS server is not
correct.
• The IEEE 802.1X switch
has problem.
[802.1X] Authentication failed • The username or
password that the user
entered is not correct.
• The certificates uploaded
are wrong.
Certificate verification Failure • A CA certificate is not
installed in the
equipment.
• The installed CA
certificate is not valid.
• The server certificate is
invalid.
To Next Page
