3.2.5 Operation board
(1) Remove the upper cover (see 3.2.1).
(2) Disengage two tabs 0.
(3) Remove connector @ connecting the connection board and operation board.
(4) Remove operation board 0.
(5) For reassembly, reverse the disassembly procedure.
Note: Be careful not to damage the cab/e connecting the switch and the connector.
.-
3-10
