83
13-16
Float IEEE 754
User Peak Channel 2
17-18
Unsigned-16
Previous OR Channel 2
19
Unsigned-8
Last Alarm Day Channel 2
20
Unsigned-8
Last Alarm Month Channel 2
21
Unsigned-8
Last Alarm Year Channel 2
22-23
Unsigned-16
Max Temperature Channel 2
24-25
Unsigned-16
Min Temperature Channel 2
Command 133 – Read Live Channels Identifier – Response Length: 66 Bytes
Byte Number
Parsing
Parameter
0
Unsigned-8
Sensor Type Code Channel 1
1
Unsigned-8
Gas Type Code Channel 1
2
Unsigned-8
Decimal Place Channel 1
3-4
Latin-1 ASCII
Sensor ID Byte Channel 1
5-6
Latin-1 ASCII
Sensor ID Number Channel 1
7-16
Latin-1 ASCII
Sensor Part Number Channel 1
17-32
Latin-1 ASCII
Sensor Serial Number Channel 1
33
Unsigned-8
Sensor Type Code Channel 2
34
Unsigned-8
Gas Type Code Channel 2
35
Unsigned-8
Decimal Place Channel 2
36-37
Latin-1 ASCII
Sensor ID Byte Channel 2
38-39
Latin-1 ASCII
Sensor ID Number Channel 2
40-49
Latin-1 ASCII
Sensor Part Number Channel 2
50-65
Latin-1 ASCII
Sensor Serial Number Channel 2
Command 134 – Read Instrument Identifier – Response Length: 50 Bytes
Byte Number
Parsing
Parameter
0-1
Latin-1 ASCII
Instrument Config Map Version
2-17
Latin-1 ASCII
Instrument Part Number
18-33
Latin-1 ASCII
Instrument Serial Number
34-37
Latin-1 ASCII
Technician Initials
38-43
Latin-1 ASCII
Instrument Job Number
