85
13
Unsigned-8
RTC Year Channel 2
14-17
Unsigned-32
Total Operation Time (In Minutes) Channel 2
Command 141 – Write User Configuration – Response/Request Length: 36 Bytes
Byte Number
Parsing
Parameter
0-3
Float IEEE 754
Low Alarm Threshold Channel 1
4-7
Float IEEE 754
High Alarm Threshold Channel 1
8-11
Float IEEE 754
Analog Output Range Channel 1
12-15
Float IEEE 754
Cal Gas Value Channel 1
16-17
Unsigned-16
Calibration Interval In Days Channel 1
18-21
Float IEEE 754
Low Alarm Threshold Channel 2
22-25
Float IEEE 754
High Alarm Threshold Channel 2
26-29
Float IEEE 754
Analog Output Range Channel 2
30-33
Float IEEE 754
Cal Gas Value Channel 2
34-35
Unsigned-16
Calibration Interval In Days Channel 2
Table A - 4 Write Commands
Operation Commands
Operation commands are similar to write commands where specific values
are written on specific sensor to get the desired operation done. The details
are enlisted in the Table A - 5.
Command 150 – Start/Abort Selected Live Channel Calibration – Response/Request
Length: 2
Byte Number
Parsing
Parameter
0
Unsigned-8
Selected Sensor (“1 = Sensor 1” and “2 = Sensor
2”)
1
Unsigned-8
Calibration Condition (“1 = Abort” and “2 = Start”)
Command 151 – Start/Abort Selected Live Channel Zeroing – Response/Request
Length: 2
Byte Number
Parsing
Parameter
0
Unsigned-8
Selected Sensor (“1 = Sensor 1” and “2 = Sensor
2”)
1
Unsigned-8
Zeroing Condition (“1 = Abort” and “6 = Start”)
Table A - 5 Operation Commands
# # #
