12 RS485 Digital Output
59
Address
SENSORS
[64 + 2]
Nb
bytes
Data type
1
Com sensor
2 X 16
Unicode text (16 bits) 16
characters including the
final /0.
17
Status
2
Start / Stop: if in
operation, variable = 1. If
stopped, variable = 0.
18
Gas name
2 x 20
Unicode text (16 bits) 20
characters including the
final /0.
38
Range
2
Value The range is from 1
to 5000.
Range X 10 display
format.
The display format is
given in another box.
39
Display
format
2
Coded value.
40
Unit
2 X 5
Unicode text (16 bits) 5
characters including the
final /0.
45
Abbreviated
gas name
2 x 6
Unicode text (16 bits) 6
characters including the
final /0.
CAUTION, if the first 2
letters = O2: special
treatment.
51
Zone
2
Value
1 to 8
52
Instantaneou
s alarm
threshold 1
2
Value
-999 to 9999 (real value to
be multiplied like the range)
53
Instantaneou
s alarm
threshold 2
2
Value
-999 to 9999 (real value to
be multiplied like the range)
54
Instantaneou
s alarm
threshold 3
2
Value
-999 to 9999 (real value to
be multiplied like the range)
55
Average
alarm
threshold 1
2
Value
-999 to 9999 (real value to
be multiplied like the range)
56
Average
alarm
threshold 2
2
Value
-999 to 9999 (real value to
be multiplied like the range)
57
Average
alarm
threshold 3
2
Value
-999 to 9999 (real value to
be multiplied like the range)
58
Underscale
threshold
2
Value
-999 to 9999 (real value to
be multiplied like the range)
59
Overscale
threshold
2
Value
-999 to 9999 (real value to
be multiplied like the range)
60
Default low
threshold
2
Value
-999 to 9999 (real value to
be multiplied like the range)
61
Out of range
threshold
2
Value
-999 to 9999 (real value to
be multiplied like the range)
62
Integration
time alarm 1
2
Value
15 - 480 min per 1min step
(if not used, put 15 min)
63
Integration
time alarm 2
2
Value..
15 - 480 min per 1min step
(if not used, put 15 min)
64
Integration
time alarm 3
2
Value
15 - 480 min per 1min step
(if not used, put 15 min)
65
Hysteresis
2
Value
Caution, max = 5% of the
range. Always use a positive
value and not a percentage.
Table of registers
